Hella Heavy Duty Battery Master Switch Off-On Metal Key 250A 6EK 008 458-011

Hella Heavy Duty Battery Master Switch Off-On Metal Key 250A 6EK 008 458-011

The Hella 6EK 008 458-011 is a heavy-duty, high-amperage off-on battery master switch with a metal key, rated to 250A continuous and 2500A for 10 seconds.

Brand: Hella  |  Function: Off-On, removable metal key  |  Maximum Load: 2500A for 10 sec / 600A for 2 min (12/24V)  |  Part No: 6EK 008 458-011

Price:
NZ$ 172.80 excluding GST

NZ$ 198.72 including GST


or four payments of $49.68 with
Afterpay Payment Offer Learn More

Product Code:
HL 6EK008458011
Purchase Qty:



Built for trucks, buses and earthmoving equipment, this Italian-made isolator handles 2500A for 10 seconds or 600A for 2 minutes for heavy starting loads, and 250A continuously at up to 60°C with 70mm² cable and ring terminals. It is sealed to IP65 against dust and high-pressure water spray.

Mounts in a 22mm hole with up to 6mm bolts. Terminals are 2 x 10mm studs (maximum torque 22Nm). Not designed for marine use, and Hella recommends mounting it in a dry area.

  • Heavy-duty off-on battery isolator with metal key
  • 250A continuous, 2500A for 10 seconds
  • 600A for 2 minutes
  • IP65 protection
  • 2 x 10mm stud terminals
  • For trucks, buses and earthmoving equipment
  • Brand: Hella
SpecificationValue
BrandHella
FunctionOff-On, removable metal key
Maximum Load2500A for 10 sec / 600A for 2 min (12/24V)
Continuous Load250A (60°C max, 70mm² cable)
Terminals2 x 10mm studs, 22Nm max
Mounting22mm hole, up to 6mm bolts
ProtectionIP65
Made InItaly
Part Number6EK 008 458-011
