MINI RELAY 24V 20A 5PIN

Name: MINI RELAY 24V 20A 5PIN
Brand: YOUNGS AUTOMOTIVE LTD
SKU: IN ACX1942RBL

OEX Mini Relay 24V Normally Open 20A - Resistor Protected, Sealed

Price:

NZ$ 13.05 excluding GST

NZ$ 15.01 including GST

Product Code:

IN ACX1942RBL

Features

• 24V systems
• 20A
• 5 Pin
• Sealed, IP67
• Resistor protected
• Normaly open contact
• Blade terminals
• Removable mounting tab

Part No.	ACX1942RBL
Type	RELAY
Brand	OEX
Unit of Measure	EACH
Description	OEX Mini Relay 24V Normally Open 20A - Resistor Protected, Sealed
Warranty	One Year
Number of Terminals	5
Power Rating [Amp]	20
Voltage	24
Item Type	Mini Relay
Relay Action	Normally Open
Spike Protection	Resistor
Type (Mini / Micro)	Mini
Contact Material	Silver Tin Oxide
